The rotary table torque sensor is a key monitoring component in oil and gas field operation equipment such as drilling and workover, and its core function is to monitor the torque data in real time, accurately collect the torque value in the process of the rotary table driving the drill string to rotate, provide intuit...
Product advantages:
1、Only need to ensure timely oil filling after installation;
2、Anti-vibration and anti-corrosion design, suitable for harsh working conditions of oil and gas wells;
3、Solid and reliable structure, high cost performance, simple structure and convenient assembly;
| Working temperature | -40 ℃ ~ + 60 ℃ | Interface | M14x1.5 |
|---|---|---|---|
| Working medium | -40 ℃ transformer oil (special) GB 2536 |
| Name | Model | Specification | Signal form | Measurement error |
| Idler wheel type mechanical turntable torque sensor | BJZN-28A | 1.75 inch 44.45 mm | / | ±2.5% F.S |
| Idler wheel type mechanical turntable torque sensor | BJZN-32A | 2.0 inch 50.8 mm | / | ±2.5% F.S |
